Motor for Tubular Roller Shutter 20Nm 40kg

Windowo Essentials
Code: WORK 20
€ 32,70
Prices excluding VAT
Right of withdrawal not applicable (art. 59 Consumer Code).

- +

Work 20 20Nm 40kg Tubular Motor for Rolling Shutter

Motor for Rolling Shutter Technical features:

  • Pipe diameter: 45mm;
  • Limit switch: Mechanical;
  • Power supply: 230V / 50Hz;
  • Running time: 4min;
  • Absorbed power: 230W;
  • Ampere: 0,9;
  • Max turns circle: 31;
  • Speed rpm: 17 rounds/min;
  • Noise level: ≤48;
  • Degree of protection: IP44;
  • Shutter weight (indicative range): 40kg;
  • Torque: 20Nm;
  • Supplying cable: 1,5 meter - 4x 0.75.

Work 50 50nm 100kg Tubular Motor for Rolling Shutter

Dimensions: A 54,8cm, B 49,4cm.
Weight: 2,27kg.

The Work line of tubular motors with mechanical limit switch and Ø 45mm, is designed for shutters and awnings.

Complies with EN60335-1-95 and EN60335-2-97 directives / 10-2000.

Certifies CE and TUV.
